Productdetails:
|
| Markeren: | 500x500mm indoor LED display,3840hz rental LED panel,700nits RGB aluminum cabinet |
||
|---|---|---|---|
| Parameter | Value |
|---|---|
| Pixel pitch | 1.953mm | 2.604mm | 2.976mm | 3.91mm |
| LED lamp | SMD1212 | SMD1515 | SMD1515 | SMD2121 |
| Scan | 1/52 | 1/43 | 1/40 | 1/32 |
| Pixels per cabinet (500*500mm) | 256×256 | 192×192 | 168×168 | 128×128 |
| Pixels per cabinet (500*1000mm) | 256×512 | 192×384 | 168×336 | 128×256 |
| LED lifetime | 100,000h |
| Brightness | 500-700nits |
| Module size | 250*250mm |
| Module resolution | 128*128dots | 96*96dots | 84*84dots | 64*64dots |
| Refresh rate | 3840-7680Hz |
| Viewing angle (H/V) | 140° +/-5° |
| Grey Level | 14 bits |
| Avg Power consumption | 200 W/m² | 200 W/m² | 225 W/m² | 225 W/m² |
| Max Power consumption | 400 W/m² | 400 W/m² | 450 W/m² | 450 W/m² |
| Operation power voltage | 100-240V/50-60Hz |
| Operational temperature | -10°C to +40°C/14°F to 104°F |
| Operational humidity | 10-80% |
| IP rating | IP30 |
| Dimensions | 500 x 500 x 80 mm / 500 x 1000 x 80 mm |
| Weight | 7.25kg (500 x 500mm cabinet) / 12.5kg (500 x 1000 mm cabinet) |
| Serviceability | Frontal & rear service for indoor, rear service for outdoor |
